GPU Server

Leadtek Station WS2030

Ultra High-end Workstation
High Performance Computing
Ideal for AI/Deep Learning/3D rendering

Specifications

Processor

CPU	Dual Socket P (LGA 3647) 2nd Gen Intel® Xeon® Scalable Processors and Intel® Xeon® Scalable Processors Support CPU TDP 70-205W Up to 28 Cores

System Memory

Memory Capacity	16 DIMM slots Up to 4TB 3DS ECC DDR4-2933MHz RDIMM/LRDIMM Supports Intel® Optane™ DCPMM
Memory Type	2933/2666/2400/2133MHz ECC DDR4 RDIMM/LRDIMM

On-Board Devices

Chipset	Intel® C621 chipset
SATA	SATA3 (6Gbps); RAID 0, 1, 5, 10
Network Controllers	Intel® X550 Dual Port 10GBase-T Virtual Machine Device Queues reduce I/O overhead Supports 10GBASE-T, 100BASE-TX, and 1000BASE-T, RJ45 output
IPMI	Support for Intelligent Platform Management Interface v.2.0 IPMI 2.0 with virtual media over LAN and KVM-over-LAN support

Input / Output

SATA	10 SATA3 (6Gbps) ports
NVMe	1 NVMe support with M.2 Socket
LAN	2 RJ45 10GBase-T ports 1 RJ45 Dedicated IPMI LAN port
USB	5 USB 3.0 ports (2 rear, 2 via header, 1 Type A) 4 USB 2.0 ports (2 rear, 2 via headers)
Video	1 VGA port
Audio	7.1 HD Audio with optical S/PDIF
Serial Port/Header	2 COM ports (1 rear, 1 Header)

Form Factor

Dimensions and Weight

Height	18.2" (462mm)
Width	7.0" (178mm)
Depth	26.5" (673mm)
Weight	Net Weight: 46 lbs (20.9 kg) Gross Weight: 62 lbs (28.1 kg)

Drive Bays / Storage

Expansion Slots

PCI-Express	4 PCI-E 3.0 x16 (double-width) slots 2 PCI-E 3.0 x16 (single-width) slots 1 PCI-E 3.0 x4 (in x8 slot)
M.2	M.2 Interface: PCI-E 3.0 x4 Form Factor: 2280, 22110 Key: M-Key

System Cooling

Fans	4 Heavy duty fans 2 Rear exhaust fans 2 Optional Rear fans (required for Passive GPUs)

Power Supply

2200W Redundant Power Supplies with PMBus, Titanium Level Certified
Total Output Power and Input	1200W with Input 100-127Vac 1800W with Input 200-220Vac 1980W with Input 220-230Vac 2090W with Input 230-240Vac 2200W with Input 220-240Vac (for UL/cUL use only) 2090W with Input 230-240Vdc (for CCC only)
AC Input Frequency	50-60Hz

OS Compatibility

Operating Environment

RoHS	RoHS Compliant
Environmental Spec.	Operating Temperature: 10°C ~ 35°C (50°F ~ 95°F) Non-operating Temperature: -40°C to 60°C (-40°F to 140°F) Operating Relative Humidity: 8% to 90% (non-condensing) Non-operating Relative Humidity: 5% to 95% (non-condensing)
